| MODEL | HBP30-2024 PRO | HBP30-3024 PRO | HBP30-5048 PRO | HBP30-6048 PRO |
|---|---|---|---|---|
| Inverter | ||||
| Rated power | 2000W | 3000W | 5000W | 6000W |
| Output voltage waveform | Pure sine wave | |||
| Output voltage regulation | 230Vac±5% | |||
| Output frequency | 50Hz or 60Hz (±0.2Hz) | |||
| Peak efficiency | 88% | |||
| Nominal DC input voltage | 24Vdc | 48Vdc | ||
| Standby Consumption | < 2W | |||
| PV Input | ||||
| Max solar power input | 2500W | 5000W | ||
| PV max charging current | 80A | |||
| Combined charging current | 80A | |||
| Max efficiency | 98% max | |||
| PV array open circuit voltage | 145V | |||
| PV Array MPPT Voltage Range | 32~130VDC | 64~130VDC | ||
| AC Input | ||||
| AC input voltage | 230Vac ±5% | |||
| Acceptable input voltage range | 96~132VAC or 155~280VAC(For personal computers) | |||
| Nominal input frequency | 50Hz / 60Hz (Auto detection) | |||
| Transfer time | 10ms(max) | |||
| AC Charge | ||||
| Charging current @ Nominal input voltage | 30A | 40A | 35A | 40A |
| Charging Algorithm | 4-step (Li) | |||
| Output | ||||
| AC output | Terminal | |||
| Lithium Battery | ||||
| Energy | 6400wh | 12000wh | ||
| Nominal voltage | 25.6V | 48V | ||
| Battery capacity | 250Ah | |||
| Standard charging and discharge current | 20A | |||
| Maximum continuous charging & discharge current | 100A | |||
| Operation ambient temperature | ||||
| Charge | -10~50℃ | |||
| Discharge | -20~55 | |||
